Didactic System of Domestic Energy Production
Specification
This training device system can simulate and demonstrate the process of wind power generation and solar power generation, so that students have a preliminary intuitive understanding of wind and solar hybrid power generation systems. The wind generator is driven by a blower, and the solar panel is driven by high-brightness LED lights. Through relevant experiments, cultivate students' corresponding knowledge and skills.
The training platform adopts the aluminum profile column frame structure, the measuring instrument and the training power supply are built-in and integrated, and the bottom is equipped with universal wheels. Each unit is flexible, easy to use, and not easy to damage.
The experimental circuits and devices are fully equipped and can be used in combination to complete the training content of various courses.
The training platform has a good safety protection system.
Wind power generation device: The fan unit adopts aluminum profile structure, the blower can be adjusted by 90 degrees in the horizontal direction, and the overall size is 1210*1210*2440mm (length, width and height)
Solar power generation device: all aluminum alloy structure, the angle of the photovoltaic panel can be adjusted, the simulated light source can be adjusted at 120 degrees in the vertical direction, and the overall size is 1500*1500*2750mm (length, width and height)
Training platform size: aluminum profile frame structure, aluminum alloy hanging box unit form, with universal wheels at the bottom, dimensions 1610mm×800mm×1700mm (length, width, height)
The parameters of a single solar panel are as follows:
Rated peak power: 30W
Short circuit current: 1.9A
Maximum current: 1.71A
Maximum voltage: 17.6V
Short circuit current: 1.87A
Open circuit voltage: 21.6V
