Electrical Skills Training Workbench
Specification
This trainer is double sides, two work stations for two students, every work station has independent power, stainless patch board, hanging box.
The control circuit of electromotor
Reduced voltage starting self-control circuit of time relay
Contactor self-locking forward control circuit
Contactor self-locking forward control circuit with overload protection
Inching and continuous mixed forward control circuit
Forward and reverse control circuit of contactor interlocking
Forward and reverse control circuit of button and contactor double interlocking
Position control circuit( also called travel control circuit or limit control circuit)
