Electrical Protection Training Workbench

Electrical Protection Training Workbench

Overview
It can through training, let students be familiar with various electric accident reasons so as to prevent electric accident occur. Through learning, students will learn of how the accident occurs, and take cautions on electric accident, so as to enhance the ability of prevent accident, solve electric accidents. Students can learn many safety protection mode in the trainer.
Feature
Training workbench use aluminum column, testing measures, inner integrated training power box. It is easy to use, and it is not easy to be broken.
Modular structure: it has many modules, and it can achieve many training projects, please see the experiment list later.
It has good safety protection system, all the electric terminals select safety plug terminals, the whole set can
be connected to ground, if there is electric leakage occurs, students can ct off power immediately, so as to protect themselves.
Input power: single phase three wire, 220V±10% 50Hz
Dimension: 1600mm×800mm×1800mm
Whole capacity:＜2.0KVA
Weight: ＜100kg
Work condition:
Environment temperature:-10℃～+40℃
Relative humidity: ＜85%(25℃)
Product composition
Training workbench
Training workbench surface use anti-fire treatment, it has a long life to use, and has a beautiful outlook.
Power control panel
Single phase three wires power input, it goes through electric leakage breakers to be controlled. It has
emergency stop button, when in emergency circumstance, press it, and breakers cut off power supply.
Equip with power indicator, power output plug, safety power output terminal.
Equip with components
Transformer
round resistor meter
tramegger
Electric cables 25 eas
Training content
Insulation protection training and experiment
Insulation resistor testing
Insulation characteristic testing
insulating medium experiment
Low voltage protection experiment
Safety voltage testing
Transformer characteristic testing
Ground experiment testing
Ground type
Ground bar usage
Ground power system and don’t connect ground power system
Multi points network testing
Ground resistor testing
Ground rod usage and testing
Current protection experiment
Zero sequence current application
Current leakage breaker protection
Over current fault protection
Voltage protection experiment
Zero voltage protection experiment
Over voltage experiment
Voltage type breaker protection experiment
Circuit resistor testing experiment
Circuit resistor testing
Wire resistor testing
