Open Loop Control Drive Trainer

Open Loop Control Drive Trainer

This trainer include various industrial class inverter and various sensor, it can demo typical circuit. Through training, students can be familiar with inverter control electrical feature, master control principle and control mode, cultivate students skill on knowledge.
Feature
Training workbench use aluminum frame structure, with cabinet and workbench, there are four wheels at the bottom of cabinet, and with brake lockers for wheels. Inner power box, and can use a long time.
Inverter use open structure installation panel, students can see wire and equipment function, finish many training content.
Students can add or decrease unit according to requirements.
Training equipment has safety protection system.
Input power: three phases, five wires, 380V±10%, 50Hz
Dimension: 1600mm×800mm×1300mm
Whole capacity:＜2.0KVA
Weight:＜100kg
Work condition:
Environment temperature : -10℃～+40℃, Relative humidity: ＜85%(25℃)
Power control panel
The power control panel using aluminum alloy profile panel, enclosed body structure, and placed at the bottom of a connection as one.
Training workbench
Training workbench use aluminum structure. There are universal 4 wheels at the bottom of workbench, there are 2 breakers on wheel. The trainer can be moved or stop convenient . The workbench panel thick is 25mm high density substrate , there is high temperature high pressure anti-fire treatment process. It equip with three guide rail type drawer, 2 push and plug cabinet. The structure is sound and reliable, outlook is beautiful.
Power box
Three phases, five wires power input, it has been tested by leakage
breaker control, it has emergency stop button, you can cut off electricity
when emergency.
Control panel has two point type voltage meter, one current meter, one power meter, one non power meter.
It equipped with indicator, Europe power plug output, safety output sockets.
Inner AC 220V current output, DC 220V wound power, DC 0-220V continuous adjustable DC armature power, with short circuit protection function.
