Bluetooth Technology Experiment Box

Bluetooth Technology Experiment Box

It is based on the latetst XScale structure, PXA27X ARM series processor, main frequency can be 624MHz, add Wireless MMX technology, enhance multi media process ability, ensure CPU capacity, decrease moving equipment consumption, it is widely used in PDA, intelligent mobile, PMP etc. The core development desk with expand module, support Linux 2.4.20/ 2.6 and Windows CE 5.0 operate system, students can learn Apache Web Server, Linux、WinCE drive, QPE experiment, network Sokcet communication ability, we supply double lines European port, and experimental example such as GPS experiment, GSM/GPRS experiment, non-contact RF card, Bluetooth experiment, DC/step motor experiment, fingerprint identification etc( select optional expand module to do experiment).
Core hardware resource
Processor: Intel XScale PXA270 520MHz
SDRAM:64Mbyte
FLASH:32Mbyte
Ethernet10/100M Ethernet controller (LAN91C111)
SUPERIO: Winbond 83977
CPLD: Xilinx 95144 (117 User IO)
One USB interface, one USB HOST USB CLIENT
10/100M Ethernet interface
Camera Interface
Infrared communication interface
Serial Port: 1 × RS485, 5 × RS232 (where 3 is fully functional), 1 × IRDA (infrared) Interface
Parallel: Standard DB25 parallel port
Expansion Interface: 2 × 96pin European seat, leads all bus signals
True Color TFT LCD screen with a resolution of 640 × 480,8 inch color LCD screen (Optional touch screen: UCB1400BE, four-wire resistive)
Audio: AC97 standard UCB1400BE, audio input / output
LCD Interface: can be accessed from 15.1 to 3.5-inch TFT, STN screen; system as standard pick TFT 8 "(640 × 480) screen.
VGA output interface: can connect analog CRT monitor or LCD monitor
Video Output ports: Composite video and S-video port
Touch screen: UCB1400BE, four-wire resistive
PS / 2 interface: can be connected to PS / 2 mouse and keyboard
PCMCIA Interface: PCMCIA interface can be connected to the wireless network card, CF card can be transferred
IDE interface: can be connected to the notebook hard drive
SD / MMC card interface: can connect SD card or MMC card
SMC card interface: can connect SMC card (expandable NAND FLASH)
Interface: 20pin
EEPROM: I2C Interface 24C16
AD: 1 potentiometers voltage input, a temperature sensor input
DA: 8bit
RTC: Real Time Clock
Function keys: 1
Keyboard: 4 × 5 keyboard matrix
LED: Several
LED array: 8 × 8 light-emitting diode array
Seven-Segment LED: 4 × 7 segment LED
Bluetooth & 802.15.4 extension module: two common local wireless communication protocol, which enables wireless data transfer and wireless control, information appliances and is a core part of wireless sensor networks
