Electrical Machines Transformer Trainer

Electrical Machines Transformer Trainer

This training set include various of transformers, students can be familiar with various types of transformers features, control principles, and knowledge through training and experiments. It is suitable for students in vocational schools, technical schools, colleges. This trainer include various types of DC motors, through experiments, students can be familiar with DC motor features, master its control principles and control mode, it will cultivate students’ technical skills and knowledge. The trainer is suitable for vocational school students, technical schools students, colleges students who major in electrical technology, electronics technology, mechatronics technology etc.
Training workbench use aluminum column structure frame, it include meter box and power box to test and measure technical parameter, it is easy to use and it is not easy to be broken.
Equipped with transformers, students can make combination, and finish many training contents and experiments.
Training workbench has high safety system.
Technical parameter
Input power: three phases, five wires, 380V±10% 50Hz
Dimension: 1600mm×800mm×1800mm
Whole capacity:＜1.5KVA
Weight: ＜380kg
Work environment:
Environment temperature: -10℃～+40℃
Relative humidity:  ＜85%(25℃)
Product consist of
Power control panel
Power control panel use aluminum structure metal panel, all close type Boxes structure
Training workbench
Training workbench use anti fire board surface, it is very sound and not easy to be broken, it has a beautiful outlook.
Power control panel
Single phase, three wire power input, it has been tested by leakage breaker control, it has emergency stop button, you can cut off electricity when emergency.
Control panel has one point type voltage meter, one current meter, one power meter, one non power meter.
It equipped with indicator, Europe power plug output, safety output sockets.
Inner AC current and DC wound power, with short circuit protection function.
Single phase transformer
Single phase ring shape transformers
Single phase self-coupling transformers
Three phase transformers
U shape and I shape Silicon Steel
Transformer wound 2 groups
1500 Ohm resistor 4 pcs
Resistor load
4MM SAFETY  electrical cables
Series wound DC machines
Parallel wound DC machines
D C compound generator
DC servo motor
Motor coupling
Adjustable resistor: 0～900Ω/0.5A adjustable resistor
Low voltage components: breaker, AC contactors etc.
Training content
1 Single phase transformer experiments
Single phase transformer static test
Single phase transformer empty load and load characteristic
Single phase transformer voltage short and current short circuit test
Single phase ring shape transformer empty load and load characteristic test
Single phase ring shape transformer short circuit voltage and short current test
Single phase self-coupling transformer experiments
Self-coupling transformer principle features
Self-coupling transformer static test
Self-coupling transformer operation and function features
Self-coupling transformer load testing features
Three phases transformer experiments
Three phases transformer principle features
Three phases transformer static test
Three phases transformer star connection and function
Three phases transformer delta connection and function
Transformer comprehensive training
Transformer installation and circuit wire check
Winding DC cold resistor test
Insulation resistor test
Transformer over load experiment test
Transformer empty load experiments
Transformer temperature rise experiments
Transformer load experiments
5 Series wound DC machines experiments
Motor function and transmission set test
Motor technical parameter static test
Motor control circuit connection and function
Motor function technical parameter test
Parallel wound DC machines
Motor function and transmission set test
Motor technical parameter static test
Motor control circuit connection and function
Motor function technical parameter test
D C compound generator
Motor function and transmission set test
Motor technical parameter static test
Motor control circuit connection and function
Motor function technical parameter test
DC servo motor
Motor function and transmission set test
Motor technical parameter static test
Motor control circuit connection and function
Motor function technical parameter test
Motor speed adjust control
Motor comprehensive training
Motor installation and circuit check and test
Winding DC cold resistance test
Insulation resistor test
Motor speed exceed experiments
Motor empty experiments
Motor temperature rise experiments
Motor stalling experiments
Motor load experiments
