Technical Specification

Product description

This device can be used to train students to master the theoretical knowledge and practice skills of the commercial refrigeration system.

Features:

1. Selection of cooling stage via solenoid valves

2. Individual and parallel operation of the cooling stages possible

3. Cooling stages: insulated chambers with air-cooled evaporators

4. Semi-hermetic piston compressor, air-cooled condenser

5. All fans are speed-controlled

6. Mobile refrigeration unit with normal cooling stage and deep-freezing stage

7. Built in faults set module.

Technical specification

1. Compressor:

- Power consumption: approx. 13TOW

- Refrigerating capacity: 2080W at -10/40℃

2. Condenser with fan:

- Capacity: 1935W

- Heat exchanger surface area: 2.5m²

3. Normal evaporator with fan:

- Capacity: 78W

- Heat exchanger surface area: 1.12m²

4. Deep-freezing evaporator with fan:

-Capacity: 130W

- Heat exchanger surface area: 1.88m²
